Gremsy Two-Axis T3v3
Dimensions & Camera Cage
Front Mount & Roll-Tilt Mount
Dimensions - Front Mount & Roll-Tilt Mount Camera Cage - Front Mount & Roll-Tilt Mount
Pan-Tilt Mount
Dimensions - Pan-Tilt Mount Camera Cage - Pan-Tilt Mount
Camera Compatibility
Sony A7R (mk I - IV)

Sony A7R (mk I - IV)

Sony A7S (mk I - III)

Sony A7S (mk I - III)

Sony A9 (mk I - II)

Sony A9 (mk I - II)

Sony A1

Sony A1

Wiris Security

Wiris Security

Panasonic GH3, GH4, GH5, GH5S

Panasonic GH3, GH4, GH5, GH5S

Phase One iXM50/100

Phase One iXM50/100

UMC-S3CA

UMC-S3CA

General
Built-In Functions
  • 1. Operation Modes
    • Gimbal ON/OFF
    • Lock mode
    • Follow mode / Mapping mode
  • 2. Temperature Sensor
    • Bottom Mount
    • - Option 1: Pan & Tilt (PT Mount)
    • - Option 2: Roll & Tilt (RT Mount)
    • Front Mount
  • 3. Gremsy Stabilization Technology
  • 4. USB-C for data transmission *(2.0 speed)
  • 5. Multiple Drone/Control Platform supported
  • 6. SDK for integrator
Mechanical & Electrical Characteristics
Working Current
  • Static current: 300mA/14.5V
  • Dynamic current: 600mA/14.5V
  • Locked motor current: 3.5A/14.5V
Operating Temperature
32° F ~ 122° F (0° C ~ 50° C)
Weight
1.6lbs (745g)
Gimbal Dimension
198(D) x 247(W) x 165(H)
Peripheral
Camera Tray Dimensions
  • Maximum depth from the center of gravity on camera base plate: 100mm
  • Maximum height measured from top of camera base plate: 120mm
  • Maximum width: 152mm
Input Power
15-52V
Connections
CAN, UART, S-Bus, Spektrum, PPM, Bluetooth, Micro HDMI, USB 2.0, USB-C (The USB-C only supports USB 2.0 speeds)
PC Assistant Software Requirements
Windows 10 or above, MacOS 12.0 or above
Mobile Assistant Software Requirements
Android 10.0 or above, iOS 14.0 or above
Working Performance
Maximum Payload
3.7lbs (1700g)
Angular Vibration Range
± 0.02°

Front Mount & Roll-Tilt Mount
Pan-Tilt Mount
Maximum Controlled Rotation Speed
  • Tilt axis: 180°/s
  • Roll axis: 180°/s
  • Tilt axis: 180°/s
  • Roll axis: 180°/s
Mechanical Endpoint Range
  • Tilt axis control: ±150°
  • Roll axis control: +80° to -264°
  • Tilt axis control: +45° to -239°
  • Roll axis control: +80° to -264°
Controlled Rotation Range
  • Tilt axis control: ±120°
  • Roll axis control: ± 45°
  • Tilt axis control: +35° to -229°
  • Roll axis control: +70° to -254°
